WIRELESS COMMUNICATION INTERFACE
-------------------
Manufacturer: Monitortech(USA)
Model: WIRELESS COMMUNICATION INTERFACE
Introduction:
The Silo Patrol® SMU SE inventory monitor "smart" sensors can be used in conjunction with the SiloTrack™ Inventory Management PC-Based Software or HMI2 operator interfaces. Communication between the Model SMU SE "smart" sensors and the SiloTrack software or HMI2 control console is accomplished via 2-wire RS-485 communication format. The Wireless Communication Interface can be used to replace the RS-485 wiring between the "smart" sensors and the PC. With reliable and affordable technology, the Wireless Communication Interface can be used to lower the cost of installation and to overcome obstacles that make hardwiring impractical or impossible.
Technical Data:
|
Power Requirements:
|
115/12 VAC (±15%); 7VA; 50/60Hz
230/12 VAC (±15%); 7VA; 50/60Hz
|
|
Ambient Operating Temp:
|
-40° to +150° F (-40° to +65° C)
|
|
Data Input Signal:
|
RS-485 half-duplex, isolated, proprietary protocol
|
|
Alt. Data Input Signal:
|
RS-232
|
|
Wiring Distance:
|
4,000 ft. (1,220 m)
|
|
Radio Output:
|
900MHz (North America); 100mw
|
|
Radio Sensitivity:
|
-110dBm
|
|
Conduit Entry:
|
Two (2) 0.88in (22.4mm) dia. holes
|
|
Indicators:
|
Red LEDs: Query, Reply and Error
Green LED: Power
|
|
Housing:
|
Powder coated die cast aluminum; ENCLOSURE TYPE 4
|
|
Mounting:
|
Desk, wall or pipe/rail
|
------------------------------------------------------------------------------------------------------------------------------------
