Auxiliary Output Enclosure
-------------------
Manufacturer: Monitortech(USA)
Model: AOE SERIES
Introduction:
A unique feature of the SiloPatrol® SE or Flexar® Inventory Management Systems is the ability to incorporate both relay and analog outputs with a standard "smart" output sensor system. These auxiliary relay and/or analog outputs are provided in optional Auxiliary Output Enclosures (AOE) and are programmed and controlled by either the HMI2 or SiloTrack™ PC-based Inventory Management Software.
One analog output and up to four relays (two for HMI2; four for SiloTrack) can be assigned to each of the “smart” output sensors. These can be used to tie the Inventory Management System into remote control systems, sound alarms and for local control functions.
Up to 16 analog outputs or 32 relays can be provided within a single enclosure. Up to four AOE’s can be connected on a single network. The AOE can be located close to the point of hardwiring termination minimizing wiring and installation costs.
.
Technical Data:
|
AUXILIARY OUTPUT ENCLOSURE (AOE)
|
|
Power Requirements:
|
115 VAC or 230 VAC, 50/60 Hz
|
|
Power Consumption:
|
25 VA max
|
|
Operating Temperature:
|
-4° to +131°F (-20° to +55°C)
|
|
Communication:
|
RS-485 half-duplex, isolated, proprietary protocol
|
|
Analog Outputs:
|
4-20mA, 16 max, 4 per card, non-isolated, 500 ohm max loop resistance, 10 bit resolution, zero/span set via HMI/SiloTrack™
|
|
Relay Outputs:
|
SPST, 5A @ 250 VAC, 32 max, 8 per card, visual LED per relay, assignment and action set via HMI/SiloTrack™
|
|
Enclosure:
|
Painted aluminum
|
|
Overall Dimensions
(HxWxD):
|
2-Card: 11.02 x 9.05 x 4.33 in
(280 X 230 X 110 mm)
4-Card: 15.74 x 9.05 x 4.33 in
(400 X 230 X 110 mm)
|
|
Enclosure Rating:
|
NEMA 4; IP66
|
|
Approvals:
|
CE Mark
|
------------------------------------------------------------------------------------------------------------------------------------
